- Confirm the vertical stroke of the take out robot.
To confirm the vertical stroke, we need our customer to provide below information about the injection molding machine:
A: Distance from nozzle centre to fixed platen. This information affects the vertical stroke of the take out robot.
B: Distance from fixed platen to safety door top. This information tells us how much space are allowed for robot to move products out of the injection machine. If vertical space is not enough, products can’t be taken out successfully.
C: Distance from the safety door top to crane. This information decides if customer should use a single stage arm take out robot or telescopic arm take out robot. If space allows, we would recommend our customer to use single stage arm take out robot because it’s cheaper, can help our customer reduce cost. If space not enough, we will recommend our customer to use telescopic arm take out robot.
D: Product size, shape, weight and product photo. This information give us idea about the type of jig or EOAT that will be used to take out the products.
Normally, A + B + height of the jig + product height = vertical stroke of the take out robot. Also, we should take product weight into consideration in case robot can’t bear the weight of the products. For example, 500(A )+ 160(B) + 50mm (height of our jig) + 50mm ( product height) = 760. We should use a take out robot which vertical stroke is greater than 760mm - A 800mm or 900mm robot.
- Confirm the type of take out robot.
We have swing type robot and traversing type robot (one axis , two axis , three axis, five axis, one arm, two arms).
1+2 = the take out robot.
For example, if you need a 800mm traversing type one axis robot, one arm. Our model is: RHD800IS ( RHD means traversing type one axis robot, 800 means robot vertical stroke 800mm, I means single stage, S means single arm).
For more detailed explanation about our take out robots, please refer to our article “ What type of take out robot do you need ?”
